Bianchi Infinito XE Disc Ultegra

Bianchi Infinito XE Disc Ultegra
$3,675.00
Color:
CK16/Black Gloss
Please select options
Sorry, this item is currently not available. Please call us at 205-985-0001 for the latest info and alternatives to this product.

Details

The Bianchi range of endurance bikes takes the cutting-edge technology used in our racing bikes and gives it a more comfortable geometry so you can put the miles in without compromising comfort.

Geo Chart

Geometry Chart:
Size47cm50cm53cm55cm57cm59cm61cm
A (mm) 420 450 480 500 520 540 560
B1 (mm) 515 525 535 550 560 575 585
C (mm) 415 415 415 415 415 420 420
D (mm) 68 68 68 68 68 68 68
E (mm) 120 135 150 165 180 195 210
F (mm) 581 583 588 593 599 608 612
G 74.5° 74.5° 74° 73.5° 73.5° 73° 72.5°
G1 70.5° 71.5° 71° 72° 72.5° 72.5° 72.5°
H (mm) 43 43 43 43 43 43 43
I (mm) 375 375 375 375 375 375 375
X (mm) 371 375 377 381 386 391 392
Y (mm) 521 539 553 569 585 600 614
WB (mm) 986 988 993 999 1004 1018 1023

Specs

Frame Infinito XE Disc carbon, tapered HT 1.1/8"- 1.5", Mechanical/Electronic Di2 shifting compatible, compatible with 32" tire, PressFit 86,5x41mm BBset, thru axle 12x142mm
Fork Bianchi Full Carbon Disc, 1.5" head, thru axle 12x100mm, compatible with 32" tire
Rims Fulcrum Racing 918 DB, 2WF-R C19, thru axle front 12x100mm - rear 12x142mm
Tires Vittoria Zaffiro Pro V 700x28
Bottom Bracket Shimano SM-BB71-41B, PressFit
Crankset Shimano Ultegra FC-R8000 50x34T, Hollowtech II
Shifters Shimano Ultegra ST-R8020 2x11sp, hydraulic disc brake, Shimano Ultegra ST-R8025 2x11sp, smaller lever size for sizes 47/53cm
Front Derailleur Shimano Ultegra FD-R8000
Rear Derailleur Shimano Ultegra RD-R8000 GS 11sp
Cassette/Freewheel Shimano Ultegra CS-R8000, 11-12-13-14-16-18-20-22-25-28-32T
Chain Shimano Ultegra CN-HG701-11, 11sp
Brakes Shimano BR-R8070
Rotors Shimano SM-RT800 Center Lock, diam. 160mm
Brake Levers Included w/shifters
Handlebars Velomann Compact, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm
Tape/Grips La Spirale Ribbon cork
Stem Velomann, 3D Forged alloy 6061, rise +/ - 7°, height 38mm, Oversize, 1.1/8"
Headset FSA NO.42/47CF/ACB/5D
Seatpost Velomann alloy shaft 2014, head alloy 6061, hardwares: Steel, Setback 25mm
Saddle Velomann 1966 rail steel black, open, cover PU, lenght/wide 250x148mm

* Subject to change without notice.

Part Numbers

Option UPC MPN
CK16/Black Gloss / 47cm 08032809829065 YRB6DT475K
CK16/Black Gloss / 50cm 08032809829089 YRB6DT505K
CK16/Black Gloss / 53cm 08032809829102 YRB6DT535K
CK16/Black Gloss / 55cm 08032809829126 YRB6DT555K
CK16/Black Gloss / 57cm 08032809829140 YRB6DT575K
CK16/Black Gloss / 59cm 08032809829164 YRB6DT595K
CK16/Black Gloss / 61cm 08032809829188 YRB6DT615K

Reviews
